Display |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Model |
DHI-LM27-P301A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
LCD Technology |
IPS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backlight |
ELED |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Size |
27 inch |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Aspect Ratio |
16:9 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Viewing Size |
596.74 (H) × 335.66 (V) mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen-to-Body Ratio |
≥90% |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Viewing Angle |
178° (H) / 178° (V) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display Mode |
Horizontal |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pixel Pitch |
0.2331 mm × 0.2331 mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pixels Per Inch |
108.79 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
2560×1440 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Refresh Rate |
100 Hz |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display Color |
16.7M colors |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Color Gamut |
99% sRGB (typ.) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Brightness |
350 cd/m² (max) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Contrast Ratio |
1000:1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Response Time |
OD 5 ms |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lifespan |
30,000 hrs |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Surface Treatment |
Haze 25%, 3H |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Flicker-free Technology |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Low Blue Light |
Hardware blue light protection |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Device Ports |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Input Port |
1 × HDMI 2.0 (1920 × 1080@100 Hz), 1 × DP 1.4 (1920 × 1080@100 Hz), 1 × TYPE-C (65 W) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output Port |
1 × Audio out |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power & Environmental Conditions |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
100–240 VAC (±10%), 50/60 Hz |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Type |
Built-in Power |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
25 W (basic), 35 W (typ.), 140 W (ma×) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Standby Power Consumption |
≤0.5 W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
0 °C to +40 °C (+32 °F to +104 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
10%–85% (RH) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature |
–20 °C to +60 °C (–4 °F to +140 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Humidity |
5%–90% (RH) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Inclined Angle |
-5° / 20° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Left and Right Rotation Angle |
-45° / +45° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Vertical Rotation Angle |
-90° / +90° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Height Adjustment |
120 mm (4.72") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions |
613.3 mm × 367.3 mm × 64.9 mm (24.15" × 14.46" × 2.56") (W × H × D), without wall-mount bracket |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Package Size |
915 mm × 454 mm × 163 mm (36.02" × 17.87" × 6.42") (W × H × D) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Unilateral Splicing |
U/L/R/D: 8.3 mm/8.3 mm/8.3 mm/19.3 mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
5.9 kg (13.01 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
8.23 kg (18.14 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing Color |
Black |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Control Mode |
Five-button |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Status Indicator Light |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wall Mount VESA |
75 mm × 75 mm (2.95" × 2.95") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Accessory |
Power cord, stand, base, HDMI cable, TYPE-C cable, user's manual, legal and regulatory information etc. |
